From £50.26
Stocked|Dispatched within 48-72 hours for Standard White, 2 weeks for colour
Over 60 Colours Available

23 RAL colours, 31 special finishes & 6 feature finishes


Download the latest brochure page or the fitting instructions

Spread the Cost

A convenient and cost-effective way to manage your budget.

Low Water Content

Less water in your system means better efficiency and cheaper bills

Colour Co-ordination Available


We understand that many interior designs can be enhanced with carefully applied colour co-ordination or contrasts to create a standout feature. Today we have a huge choice of brands, exciting colour palettes and tones to choose from for our walls and woodwork, providing the opportunity to create truly stunning rooms.

If you are looking to create a uniquely personal look, using colours from either popular or premium paint brands, we can take your chosen colour and create a highly durable powder coat finish that will allow your radiator to blend in with your wall colour, or stand out if you want to make a statement!

390mm x 1220mm in Gun Metal Grey

440mm x 1060mm in Azurite

Product Specification:

  • Italian Design and manufacture
  • Sectional Aluminium
  • CE/UKCA approved & certified to BS EN442
  • 4 heights; 390mm, 440mm, 590mm & 690mm
  • 16 widths; ranging from 420mm to 1620mm
  • Output ranging from 1399 to 9690 (BTU's at Δt 50ºc)
  • Maximum working pressure 6 bar
  • Maximum working temperature 100°C

Product Information:

Low Water Content
Hydronic Radiator
White RAL 9010 as standard
23 RAL colours, 31 special finishes & 6 feature finishes available
Colour Co-ordination Available
Delivered with in 48-72 hours for white & 2 weeks for colour
10 year guarantee

Pricing Tables

All prices and outputs are given per section in the tables below. Price per section includes plugs, bushes, diverter, wall brackets and wall ties.
Alternative mounting options must be selected, these will include the air vent and appropriate number of wall ties.
Made To Order Anconas® are supplied factory assembled up to a maximum of 40 sections. For radiators outside these parameters,  Please contact our Customer Services to discuss.

Description Image

Choosing the right material


Aluminium is a highly efficient, conductive material that will heat up very quickly after the central heating is turned on, giving you total control over your central heating system.

Aluminium radiators can tick a lot of boxes for homeowners. The main benefit of aluminium designer radiators is that they will heat up faster than other material (and cool down quickly). This is because aluminium is a superconductor and so responds quickly to thermostatic changes. Radiators made from this material are therefore highly efficient and make it easy to control the temperature of the space. Aluminium is less flexible to work with than steel so there tend to be fewer variations in designs to choose from.

Another benefit of aluminium designer radiators is their light weight. Not only does this make the installation process much easier, but it also makes them suitable for a wide range of projects, as they can be hung on most walls.




More Information
CertificationUKCA, CE & EN442
Dual FuelNo
Fuel TypeHydronic
Guarantee10 Years
Pipe Centres From Wall67mm to 71mm
Pipe Centres Left To RightNo. of sections x 80mm + 20mm + valves
Delivery48-72 hours for Standard White, 2 weeks for colour


Product Dimensions
Height(s) (mm) 390mm - 690mm
Width(s) (mm) 80mm - 80mm
Technical Data

What is BTU?

The BTU rate of a radiator is how much heat the radiator will emit, and is there to help you decide if a radiator is the correct size for your room or not. It’s important to know how much heat your room needs in order for your system to work efficiently.

BTU Calculator

Italian Design

Over 60 Years' Experience

Over 52 Designs

With over 60 years of experience providing the best in contemporary and designer radiators, we can help you choose the perfect solution for warming your home.

Our designer radiators are suitable for every room: Living rooms, Hallways, Kitchens, Bedrooms, Bathrooms and Conservatories.
